8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
  • 8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
  • 8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
  • 8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
  • 8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
  • 8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM
8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM

8 Ports GSM VOIP SK Gateway For Call Origination and Termination in GSM

    A lot of clients now are complaining about the blocking issues. First, you may know why the Operator blocks you frequently? Second, what are the rules for the blocking? Third, how can we reduce it, even avoid it? There are some rules I have found out for you.

  • Description
  • Features
  • Application
  • Remarks

Why choose SK gateway ?


A lot of clients now are complaining about the blocking issues. First, you may know why the Operator blocks you frequently? Second, what are the rules for the blocking? Third, how can we reduce it, even avoid it? There are some rules I have found out for you.


#Operator detects you SIM cards are abnormal. The explain is because the Operator affirms your SIM cards are not being used by a human, instead some certain devices.

Solution: On one hand, the SK gateways are designed with a function which copies a human’s behavior of using a SIM card and makes it look like a human is using it. On the other hand, the SK gateways also can copy a human’s behavior of sending SMS and making calls among the ports. All the functions can be set by the setting page of the SK gateways.


#Operator detects the calls of its continuous minute. Once the SIM cards reach a certain continuous minute, SIM cards block.

Solution: Our SK smart gateways can be inserted 4 SIM cards each port and support the SIM cards making calls circularly itself. For this advantage, you can set when 1 SIM card reaches a certain continuous minute, then goes to next SIM card to make calls. Also, we can set it sending SMS more frequently to reduce the blocking.


#Operator detects if your SIM cards are making call according to the same base stations.

Solution: Normally, when people are making calls, our phones are searching for the best signal from the base stations and they will not always use the same base stations; they will move and change different base stations. According to this Operator’s blocking rules, our SK gateways can change different base stations to make calls, even if you’re making calls.


#Operator detects the IMEI No. of SIM cards and blocks it.

Solution: Our SK gateways can be set to change IMEI No. Automatically to avoid blocking issues.


SK8-8 and SK8-32 support 8 calls at one time,which is different in the number of SIM cards it can insert. SK8-8 can insert 8 SIMs while SK8-32 can insert 32 SIMs at most,means 4 SIMs in one channel.pls check as follow pic:


8 ports with 8 SIMs GSM VOIP Gateway:




8 ports with 32 SIMs GSM VOIP Gateway:



Special Features:

ModelSK8-8 / SK8-32
Number of Channels8 channels
FrequencyGSM: 850/900/1800/1900MHz
CDMA:800/1900MHz
WCDMA:850/900/1800/1900/2100MHz
4G :
EC20-E
FDD LTE: B1/B3/B5/B7/B8/B20
UMTS: B1/B5/B8
GSM: 850/900/1800/1900MHz
EC20-A
FDD LTE: B2/B4/B5/B12/B17
UMTS: B2/B4/B5
GSM: 850/1900MHz
EC20-C
FDD LTE: B1/B3/B8
TDD LTE: B38/B39/B40/B41
TDSCDMA: B34/B39
UMTS: B1/B8
GSM: 900/1800MHz
SIP SpecificationSIP/2.0 RFC3261
Session Timer RFC4028
STUN
Network ProtocolsDHCP / PPPoE / VPN(pptp)
NTP
Telnet / HTTP / FTP / TFTP
Encryption:Security,VOS2000,RC4,XOP.Base64
Telephony FeaturesHot-line call ,Dial plan, Speed dial, Phone book, CDR, LCR, White/Black list
Telephony SignalingDTMF tone dectection/generation
DTMF relay: in-band, RFC 2833 and SIP info
Call forward: unconditional, no answer and busy
N-way conferencing
Caller ID display/generation, Mobile Number Portability
Voice CapabilityVoice codecs: G729a/b/e,G723.1,G.711 A/U law, iLBC
Echo cancellation
Silence suppression & detection(VAD, CNG)
Adaptive jitter buffer
Volume adjustable
IVR customized
Number of Ports1 WAN 10/100Base-T ethernet(RJ-45 connector)
1 LAN 10/100Base-T ethernet(RJ-45 connector)
1 Console(USB)
LEDs1 Power and 8 groups of card online and running status indicator
Power Supply100-240VAC, 50 - 60 Hz IN, 12V/5A OUT
Operating EnvironmentOperating temperature: 0 - 50ºC
Operating humidity: 10 – 90%RH
Warranty12 Months


Mobile Features:

SMS Send, Receive and Forward(GSM/SIP/HTTP)

SMS Inbox

AT Command , USSD

SMS Format: PDU/TXT

PIN Code Management

CDMA Delay Answer

GSM Polarity Reversal

Carrier Selection

Caller ID Hidden(need SIM Card support)


Maintenance and Management:

Multi-language Interface

USB Serial COM

Configuration Backup and Restore

Support HTTP/TFTP Upgrade

Call statistics: ASR,ACD,PDD

Remote Management System
