128 Ports SIM Bank
  • 128 Ports SIM Bank
  • 128 Ports SIM Bank
  • 128 Ports SIM Bank
  • 128 Ports SIM Bank
  • 128 Ports SIM Bank
128 Ports SIM Bank128 Ports SIM Bank128 Ports SIM Bank128 Ports SIM Bank128 Ports SIM Bank

128 Ports SIM Bank

    SMB128 is a SIM Box for 128 SIM cards, communicates directly with GoIPs with no SIM cards installed onboard. It allows centralized management and safekeeping of SIM cards. Hot swapping of SIM cards are supported so that no service interruptions to other SIM cards are incurred. SIM cards can be assigned to GoIP channels manually or dynamically with scheduled re-allocation algorithms. Therefore, SIM cards can virtually be moved between GoIP channels that are installed in different locations. In addition, SIM cards can be disabled based on certain triggering conditions and spare SIM cards can then be assigned to those GoIP channels. This mechanism helps to protect SIM cards from blocking and maximize the GoIP channel utilization.

  • Description
  • Features
  • Application
  • Remarks
  • Remote and centralized management of SIM cards

  • No need to switch and recharge SIM cards on-site

  • Hot swap of SIM cards without powering off the SMB-32/128

  • Free DDNS service to support dynamic public IP

  • Management of 128 SIM cards in standalone mode.

  • Free SIM Server for management of over 10,000 SIM cards

  • Counter measures for the techniques used for SIM card blocking

  • Online firmware upgrade

  • Linux Based System


  • SIM Port: 128 ports

  • Power Adapter: DC 12V/2A

  • CPU: ARM11/700MHz

  • RAM: 128M

  • Flash: 8M

  • Max power consumption: 15W

  • Net weight: 1.34KG

  • Size:29.2*22.5*5.5cm

  • Operating Tempreture: 0-45℃

  • Working Humidity:  10%-90% non condensation
